EVGA Z490 DARK K|NGP|N Edition, 131-CL-E499-KP, LGA 1200, Intel Z490, SATA 6Gb/s, 2.5Gbps LAN, WiFi/BT, USB 3.2 Gen2, M.2, U.2, EATX, Intel Motherboard

Specifications

• Chipset – Intel Z490
• SLI – 2-Way SLI
• SATA – 6 Native SATA 6.0Gbps Ports / 2 ASMedia SATA 6.0Gbps Ports
• RAID 0, 1, 5, 10
• USB – 6x USB 2.0 (4 Ports from 2 Internal Headers)
• Memory Support – 2 DIMM Dual-Channel (up to 64GB) DDR4 5000MHz+
• Capacitors – 100% Solid State
• Ethernet – 1x Intel® 2.5 Gigabit NIC / 1x Intel® Gigabit NIC
• Audio – Realtek ALC1220 7.1 Channel HD Audio + SV3H615
• Display Outputs – 1x mDP
• Fan Headers – 8 (2 CPU PWM, 6 PWM/DC)
• PCB – 10 Layers
• PCI-E Slot Arrangement – 3x16, 1x4
• NVMe Support – Yes (PCIe)

Form Factor

• E-ATX Form Factor
• Length: 12in - 304.8mm
• Width: 10.89in - 276.6mm

Features

• 150% Increased Socket Gold Content
• Built for EVGA ELEET X1 Software
• Dual EVGA Probe-It Connectors
• EVGA's Latest GUI BIOS Featuring OC Robot and In-BIOS Stress Testing
• Exclusive Z490 DARK K|NGP|N Edition box signed by K|NGP|N himself!
• Highly-Efficient 18 Phase Digital VRM
• Intel® Optane™ Memory Ready
• New Integrated EVGA Wireless Module with Intel Dual-band WiFi 6 / BT5.0 with external antenna
• Onboard ARGB and RGB Headers controlled through EVGA ELEET X1
• Onboard Clear CMOS, Power and Reset Buttons
• Onboard Temperature and Voltage Monitoring
• PCIe Disable Switches
• Realtek 7.1 Channel HD Audio + EVGA NU Audio
• Reinforced PCIe slots
• SafeBoot button resets the motherboard and goes into the BIOS with last known good settings without clearing CMOS
• Slow Mode switch locks CPU multiplier to lowest possible setting to allow users to switch between max OC and low speeds in real-time.
• SPI flashing via USB allows you to flash your BIOS without a CPU
• Triple BIOS Support

Operating System Support

• Windows 10 64bit

Product Warranty

• Dieses Produkte hat eine Garantie von 3 Jahren wenn es bei EVGA registriert wurde. Registration is recommended.
